Product Details
Place of Origin: zhuzhou
Brand Name: VKD
Certification: ISO9001
Payment & Shipping Terms
Minimum Order Quantity: negotiate
Price: Negotiable
Packaging Details: paper,then paper boxs
Delivery Time: 15-20workmonth
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5tons/month
Features: |
High Hardness |
Name: |
Tungsten Carbide Seat |
Type: |
Sleeve, Power Tool Parts |
Size: |
OEM Accepted |
Grades: |
YG6 YG6X YG6A YG8.ect |
Material: |
Tungsten Carbide, 100% Original Carbide |
Model Number: |
Customized |
Other Name: |
Mechanical Seal Sleeve |
Features: |
High Hardness |
Name: |
Tungsten Carbide Seat |
Type: |
Sleeve, Power Tool Parts |
Size: |
OEM Accepted |
Grades: |
YG6 YG6X YG6A YG8.ect |
Material: |
Tungsten Carbide, 100% Original Carbide |
Model Number: |
Customized |
Other Name: |
Mechanical Seal Sleeve |
High Hardness Tungsten Carbide Seat , Carbide Mechanical Seal Sleeve
Tungsten Carbide Seat Description
Tungsten carbide with the characters of high hardness, high strength and toughness, good wear resistance, heat resistance, corrosion resistance and a series of excellent performance, especially high hardness and wear resistance of it, even at a temperature of 500 degrees also remained same, at 1000 degrees still keeps the high hardness. We customized irregular and high difficult carbide products according to your technical drawing. Our material covers: WC-Co alloy, WC-Ni alloy, WC-Ni/Co alloy, WC-TiC-Ni/Cr alloy and more.
Tungsten Carbide Seat Application
Tungsten Carbide Seat are widely used in water pumps,oil pumps and various other pumps,especially used for high pressure or corrosion resistance pumps,flow restrictors,servo seat.
|
Product Name |
High Hardness Tungsten Carbide Seat , Carbide Mechanical Seal Sleeve |
|
Material |
tungsten carbide |
|
Color |
Black |
|
Standard |
ISO SGS CQC |
|
Grade |
YG8/YG6 (can according to customer's request) |
|
Brade |
VKD |
|
OEM |
Yes |
|
Used |
for pump and oil industries |
Common grades:
Cobalt binder grades
| Grade | Density(g/cm³) | Hardness(HRA) | TRS(N/mm²) |
| YG6 | 14.8 | 90 | 1520 |
| YG6X | 14.9 | 91 | 1450 |
| YG6A | 14.9 | 92 | 1540 |
| YG8 | 14.7 | 89.5 | 1750 |
| YG12 | 14.2 | 88 | 1810 |
| YG15 | 14 | 87 | 2050 |
| YG20 | 13.5 | 95.5 | 2450 |
Nickle binder grades
| Grade | Density(g/cm³) | Hardness(HRA) | TRS(N/mm²) |
| YN6 | 14.7 | 89.5 | 1460 |
| YN6X | 14.8 | 90.5 | 1400 |
| YN6A | 14.8 | 91 | 1480 |
| YN8 | 14.6 | 88.5 | 1710 |
