Product Details
Place of Origin: zhuzhou
Brand Name: VKD
Certification: ISO9001:2008
Model Number: bush hammer tips
Payment & Shipping Terms
Minimum Order Quantity: negotiate
Price: negotiate
Packaging Details: Plastic boxes, cartons
Delivery Time: 15-20 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: One million films a month
Product Name: |
Tungsten Carbide Insert Bit |
Grade: |
YG9C、YG11C、YG15 |
Material: |
Tungsten Carbide |
Coating: |
PVD CVD |
Feature: |
High Elastic Modulus |
Size: |
OD30XID11.5XT6.5x10 Teeth |
Package: |
Plastic Box |
MOQ: |
5 KG |
Product Name: |
Tungsten Carbide Insert Bit |
Grade: |
YG9C、YG11C、YG15 |
Material: |
Tungsten Carbide |
Coating: |
PVD CVD |
Feature: |
High Elastic Modulus |
Size: |
OD30XID11.5XT6.5x10 Teeth |
Package: |
Plastic Box |
MOQ: |
5 KG |
Brazed Tungsten Carbide Insert Bit , Carbide Cutting Inserts High Elastic Modulus
Tungsten Carbide Insert Bit Introduction
Bush Hammer is used sophisticated welding technology and selecting high quality hard alloy to casting.
Bushhammered's grit can be changed through the adjustment of spring elasticity on bush hammer. Manual grinding machine press.
Both enlarging spring's interval to reduce spring elasticity and reducing machine's press can enhance bush hammer vibration to make bushhammered face rough.
Widely used on granite,marble sandstone to make rough surface
Tungsten Carbide Insert Bit pressing:
Before mass production, we need to do a trial pressing and sintering for bush hammer carbide tips, and we check the appearances and the sizes of bush hammer carbide tips samples with micrometer, projectors etc. to ensure that the requirements of the drawings can be met before batch production;
Tungsten Carbide Insert Bit Parameters
| Properties and applications of tungsten carbide strips | ||||||||
| Grade | Density | T.R.S | Hardness | Performance & application recommended | ||||
| MPa | HRA | |||||||
| YG6 | 14.9 | 2150 | 90 | Good wear resistance, used for hard wood, used for processing original wood, aluminum section bar, brass rod and cast iron. | ||||
| YG6A | 14.9 | 1860 | 92 | Has wear resistance higher than YG6, used for processing hard wood, original wood, aluminum section bar, brass rod and cast iron. | ||||
| YS25 | 14.5 | 2150 | 92.2 | Wear resistance and strength comparatively higher, suitable for processing cast iron, non-ferrous,metal and non-metallid materials. | ||||
| YG10X | 14.45 | 91.8 | 3000 | Wear resistance and strength comparatively higher,suitable for maching cast iron,non-ferrous metal and non-metallid materials | ||||
| Other grades of strips may be offered according to customers' requirement. | ||||||||
Q1 : Are you Factory or trading company ?
We are Factory with many years of production experience.
Q2: Where is your factory located ?
We are located in Zhuzhou , is a enterprise integrating R&D, production and marketing of cemented carbide series products.
Q3: Is the price Competitive?
We have our own Factory. Thanks to strong production and distribution system, we promise to offer our customers the most competitive price.
Q4: Are the products of high quality Good performance brazed tips by stellite alloy?
Yes. All products will be tested before bulk production, and we will check the physical properties, shape and tolerance for ensuring qualified products before shipping.
