Product Details
Place of Origin: zhuzhou
Brand Name: VKD
Certification: ISO9001:2008
Model Number: SS10
Payment & Shipping Terms
Minimum Order Quantity: negotiate
Price: negotiate
Packaging Details: Plastic boxes, cartons
Delivery Time: 15-20 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: One million films a month
Product Name: |
Carbide Tipped Milling Cutters |
Grade: |
YG11C、YG15 |
Usage: |
Cutting Limestone , Tuff , Granite |
Feature: |
Indexable |
Coating: |
PVD CVD |
Place Of Origin: |
Hunan, China (Mainland) |
Brand Name: |
VKD |
MOQ: |
10 Pcs |
Product Name: |
Carbide Tipped Milling Cutters |
Grade: |
YG11C、YG15 |
Usage: |
Cutting Limestone , Tuff , Granite |
Feature: |
Indexable |
Coating: |
PVD CVD |
Place Of Origin: |
Hunan, China (Mainland) |
Brand Name: |
VKD |
MOQ: |
10 Pcs |
Indexable Carbide Tipped Milling Cutters , Ccmt Carbide Insert Cutting Tools
Carbide Tipped Milling Cutters Introduction
. Material: 100% virgin raw material also have used material with submicron grain size;
. Grade of tungsten carbide ss10 tip: Various grades for choice;
. With strict tolerance extent control, the tolerance can reach +/-0.01mm;
. Precision Ground and polished;
. Product tungsten carbide ss10 tip Types available: standard & customized
. High wear resistance,high hardness and impact toughness;
. Advanced technology , automatic pressing , HIP sintering and precision grinding;
. Having very good mechanical &chemical stability;
. High quality & reasonable price & fast delivery & best service.
Carbide Tipped Milling Cutters Grade
Grade |
Density g/cm³ |
Hardnes HRA |
T.R.S MPα |
Performance & application recommended |
ISO |
||||
| YG3A | 15.1 | 94.0 | 1700 | Suitable for finishing of cast iron and nionferrous metal. |
K01~K05 | ||||
| YG3X | 15.2 | 92.0 | 1800 | ||||||
| YG6A | 14.9 | 92.5 | 2200 | Suitable for the semi-finishing cast iron and nonferrous metals and also for the machining of manganese steel and hardened steel. |
K10 | ||||
| YG6X | 14.9 | 91.5 | 2300 | ||||||
| YG6 | 15.0 | 90.5 | 2400 | Suitable for the roughing of cast iron and light alloys and also for the milling of cast iron and low-alloy steel. | K15 | ||||
| YG8 | 14.7 | 89.8 | 2800 | K20 | |||||
| YW1 | 13.1 | 91.6 | 1600 | Suitable for finishing and semi-finishing of stainless steel and conwentional alloy steel. |
M10 | ||||
| YW2 | 13.0 | 90.6 | 1800 | The grade can be used for the semi-finishing of stainless stell and low-alloy steel and it is mainly used for the machining of railway wheel hubs. |
M20 | ||||
| YT15 | 11.4 | 91.5 | 1600 | Suitable for the finishing and semi-finishing for steel and cast steel with a moderate feed and rather high cutting speed. |
P10 | ||||
| YT14 | 11.6 | 90.8 | 1700 | Suitable for the finishing anf semi-finidhing of steel and cast steel. | P20 | ||||
| YT5 | 12.9 | 90.5 | 2200 | Suitable for the heavy cutting of steel and cast steel with a big feed rate at a medium and low speed under unfavorable working conditions. |
P30 | ||||
Size
| 12*12*4.0~5.0mm | 15*10*5mm | 20*12*3.0mm |
| 13*7*5mm | 16*12*3.2mm | 20*12*3.2mm |
| 14.6*9.8*5mm | 18*12*3.35mm | 20*12*3.35mm |
| 14*10*4.7mm | 19.6*11.9*2.9mm | 20*12*3.4mm |
| 20*12*3.5mm |
hot selling size
14.6*9.8*5mm, 18*12*3.35mm,19.6*11.9*2.9mm;20*12*3~3.5mm
Carbide Tipped Milling Cutters Application
Cutting of various stones in quarries,Cutting of limestone, tuff, granite, marble, etc.
