Product Details
Place of Origin: zhuzhou
Brand Name: VKD
Model Number: Cemented Tungsten Carbide Rod
Payment & Shipping Terms
Minimum Order Quantity: negotiation
Price: negotiation
Packaging Details: Plastic boxes, cartons
Delivery Time: 7-30 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: One million films a month
Place Of Origin: |
Hunan, China (Mainland) |
Brand Name: |
VKD |
Model Number: |
Cemented Tungsten Carbide Rod |
Rockwell Hardness: |
≥91.5HRA |
Shape: |
Fan Nozzle |
Material: |
100% Virgin Tungsten Carbide |
Advantage: |
Improved Production Rates And Efficiencies |
Dimension: |
As Customer Require |
Place Of Origin: |
Hunan, China (Mainland) |
Brand Name: |
VKD |
Model Number: |
Cemented Tungsten Carbide Rod |
Rockwell Hardness: |
≥91.5HRA |
Shape: |
Fan Nozzle |
Material: |
100% Virgin Tungsten Carbide |
Advantage: |
Improved Production Rates And Efficiencies |
Dimension: |
As Customer Require |
Cemented Tungsten Carbide Rod With High Precision Grinding Mirror Polished
Tungsten Carbide Rod Description
The tungsten carbide rods also can be called cemented carbide rods. They can be in sintered unground condition, high precision grinding and mirror polished. They’re widely used in machining carbon steel, wood, stone, aluminum , non-ferrous metals and titanium, cast iron , stainless steel, etc. The carbide rods are widely used for making PCB drills , drills , cutters, end mills &reamers , mold punches , core pins&hole drilling tools. They also can be used for making of cemented carbide stamping head, core bar and perforation tools, used as wear resistance parts of punching mold,measuring and cutting industry ,etc.
Tungsten Carbide Rod Features:
1. Made from 100% virgin raw material
2. HIP sintering
3. Stable chemical properties
4. High hardness, good compactness
5. Excellent performance and good wear / corrosion resistance
6. Blanks, high machining accuracy / precision
7. Various grades of tungsten carbide available
8. OEM customized sizes available
9. Factory’s offer
10. Strict products quality inspection
Tungsten Carbide Rod Advantages:
1. The tool shank used advanced tungsten carbide material, good rigidity and vibration resistance.
2. It extend the depth of processing and promote the precision of machining face, very deep, very long, high precision machining.
3. Reducing the tool costs. Extending the tool life.
4. Multipurpose usage, economical and practical, convenient to use, functional diversity.
eplace the cutting head rapidly when processed on machine tool and also help reduce production cost.
Tungsten Carbide Rod Grade:
| Grade | Density | T.R.S | Hardness | Properties & Applications |
| g/cm3 | MPα | HRA | ||
| YL50 | 13.86 | 2060 | 1095 | It is suitable for manufacturing punching dies and tools. |
| YU06 | 14.7 | 3000 | 2050 | It is suitable for manufacturing milling cutters for machining PCB. It is also suitable for manufacturing various kinds of solid cemented carbide tools for machining glass fiber, wood, plastics, paper and brass, Al alloy etc. |
| YU08 | 14.56 | 4000 | 1900 | It is suitable for manufacturing micro-drills with diameter less than 0.8mm for machining PCB. It is also suitable for manufacturing various kinds of solid cemented carbide tools for machining glass fiber, wood, plastics, paper and brass, Al alloy etc. |
| YU09 | 14.36 | 3900 | 1950 | It is suitable for manufacturing micro-drills for machining PCB. It is also suitable for manufacturing various kinds of solid cemented carbide tools for machining glass fiber, wood, plastics, paper and brass, Al alloy etc. |
| YU12 | 14.05 | 4000 | 1750 | It is suitable for manufacturing solid cemented carbide tools for machining steels that are corrosion and heat resistant steel, stainless steel, titanium alloy, and non-ferrous metals. |
| YF06 | 14.86 | 3800 | 1800 | It is suitable for manufacturing drills with big diameters of 3.2-6.3mm for machining PCB, drills of 0.8-3.2mm and mills, and it is also suitable for making solid carbide tools for machining aluminum alloy, plastic, PTFE and compound materials, such as carbon fiber, etc. |
| YF08 | 14.55 | 3900 | 1800 | It is suitable for manufacturing micro-drills for machining PCB. It is also suitable for manufacturing various kinds of solid cemented carbide tools for machining glass fiber, wood, plastics, paper and brass, Al alloy, etc. |
| YG6X | 14.8 | 1800 | 1550 | It is suitable for manufacturing solid carbide tools and wear parts. |
| YG8 | 14.6 | 2400 | 1400 | It is suitable for manufacturing carbide core rods and wear parts. |
| YL10.2 | 14.5 | 4000 | 1550 | It is suitable for manufacturing various kinds of solid cemented carbide tools for machining heat-resistant alloys and Ti alloy etc. It is also suitable for manufacturing micro-drills for machining PCB. |
Customized rods are available according to your request. Welcome your inquiry.
